Zeitronix Newsletter - March 2nd 2010
  1. Zt-2 Model 2010 : More than a Wideband AFR/Lambda Meter
  2. Zt-2 Model 2010 : Unique Setup Options and Advanced Features
  3. DashDAQ Series II Tips
  4. Zeitronix Data Logger 3.0.3 Released
  5. Zeitronix at the 2009 SEMA Auto Show - Pictures

1.  Zt-2 Model 2010 : More than a Wideband AFR/Lambda Meter

The Zeitronix Zt-2 Wideband Datalogging System is much more than a wideband meter.  The Zeitronix Zt-2 Model 2010 Datalogging System has features for reading many different types of sensors and signals, has both linear wideband and narrowband outputs, supports a warning/triggering system to save your engine or boost performance, and provides similar data to what one might expect with a trip to the dynamometer.  The Zt-2 System is a very high quality device, is very simple to use and is made in the USA.

Inputs:   Sensors:
AFR/Lambda   Bosch Oxygen Sensor Input
RPM   Tachometer signal, ignition coil ground, crank or cam sensor.
Boost (MAP)   50, 75, 150 psi range Zeitronix sensors (3.5, 5.0, 10 bar)
EGT   K-Type thermocouple
Throttle position   Throttle position sensors
User1   Any 0-5 volt range sensor
User2   Air Temp. sensor, Oil/Water/Transmission Temp. sensor,
50, 75, 150 psi range pressure sensors (3.5, 5.0, 10 bar),
0-5 volt range sensors

Outputs: Signal: Use:
Serial Data Output RS-232 LCD, ZR-1, ZR-2, DashDAQ, ZDL and PDA displays
Analog Wideband Output 0-5 volt Aftermarket ECU and 3rd party data logging
Simulated Narrowband Output Signal (adjustable) 0-1 volt Stock ECU input to smooth idle RPM or save gas
Warning Output 0-5 volt Trigger the ZAVT-1 Alarm/Trigger device


2.  Zt-2 Model 2010 : Unique Setup Options and Advanced Features
Multiple Gauge Support LCD Configuration and Naming Support

  • Power and run up to 3 ZR-2 Multi Gauges!  Perfect for double and triple pod stations.


  • Display AFR, Lambda, Boost/Vacuum, EGT, and User2 input values.  The User2 input supports Oil, Water, and Transmission Temp, Air Temp., Fuel and Oil Pressures, and Boost/Vacuum.


  • Back diameter size:
    2 1/16 inches (52mm) (standard pod size)


  • Bezel diameter:
    2 1/2 inches (62mm)


  • Configure outer LED ring and inner digits independently


  • Simple installation with a single connector and no external power connections needed


  • Gauges include splitters for running multiple gauges and datalogging



Select between LCD configurations showing:

  • LCD top row values of:
    "Lambda + AFR", "User2 + AFR", or "Lambda + User2"


  • Rename LCD the User2 name to AirT, OilP, or any alpha-numeric value -- symbols are also an option!


  • Bottom right value showing:
    "Boost", "Throttle Position Sensor" (TPS), or "User1" data (for any 0-5 volt sensor reading)


  • Simple installation with a single connector and no external power connections needed


  • Gauges include splitters for running multiple gauges and datalogging


3.  DashDAQ Series II Tips


The DashDAQ Series II has features for viewing, logging, calculating and converting data.  Here are a few interesting features which may be useful when using the Zt-2 and DashDAQ display...

  • View logs from the DashDAQ using the Zeitronix Data Logger software on a PC.  Set the Log File Type to Zeitronix ZDL 3.0 and create ZDL files by default.  These files can be viewed by the Zeitronix Data Logger software version 3.0 and higher.
  • Convert values: AFR to Lambda,  Analog (User) input to Pressure, and any other data values using the Rescale Signal Calculator.
For information and these and other features please see the DashDAQ Series II FAQ.


4.  Zeitronix Data Logger 3.0.3 Released


ZDL 3.0.3 Features include:

  • Preferences Dialog option added for setting screen text update rate --
    this provides easier readability of on screen text when data is being logged.

  • Online and offline help links.

  • Export to .csv or .txt files supported.

  • Fluid temperature sensor support.

    Please see the Zeitronix Data Logger Page to download the latest release.
    Release notes are also available for the latest and previous releases.


5.  Zeitronix at the 2009 SEMA Auto Show - Pictures


Click here or on a picture for additional photos.

For more information on the Zeitronix Zt-2 Wideband Model 2010 please visit the Zt-2 Product Information Page.
For questions on the Zeitronix Model 2009/earlier versus the new Model 2010
please visit the Hardware Compatibility Questions Page.
